Phil Jones Bass X2C Multifunctional Dual Band Compressor Pedal

Information

Brand New w/ Warranty. We are an authorized Phil Jones Bass dealer.

The X2C incorporates advanced compressor circuit technology and provides comprehensive tone control with a dual crossover feature which divides the signal into frequency bands ranging from 100Hz to 500Hz, ensuring exceptional clarity and dynamics in tone refinement.

 With insert jacks on each band, the X2C unlocks limitless creativity, enabling players to use various FX pedals for custom tone sculpting. Additionally, it functions as an electronic crossover, ideal for driving high-performance, 2-way bass rigs.

PJB’s Dual-Band compression design is more flexible than standard single-band compressors and provides a more natural and transparent sound. It also provides greater control over shaping and managing dynamics where standard compressors affect the entire frequency spectrum of an audio signal.

Dividing the audio spectrum into fundamental frequencies and harmonics is also effective in the enrichment of slapping techniques. The low frequencies can be compressed without changing the dynamics of the “slap”. By controlling the low frequencies and focusing the attack on the slap the amplifier will sound louder while avoiding overloading of the amp or speakers. The low band can be compressed without the harmonics being affected.

Specifications

Model: X2C

Input impedance: 220KΩ

Maximum input level: 2V

Maximum output level: 2V

Gain width: -16dB to +16dB

Noise: -85dBu (Level at Max)

Frequency response: 10-25KHz

Type of compressor: VCA compression

Threshold: 1:1 – 10:1

Attack-release: HIGH attack (400mS-20mS), release (30mS-700mS)

LO attack: (1000mS-40mS), release (200mS-2500mS)

Crossover type: 2D RC divider 100Hz-500Hz

Power supply: DC9V adapter center negative 1000mA or more recommended (not included)

Power consumption: Max 680mA

Size: 120(W) x 40(H) x 144(D)mm (excluding protrusions)

Weight: 550g (1.2lb)
